Locinox MAG - Electromagnetic Locks with Handles

The Locinox® MAG Electro-magnetic Lock with Integrated Handles is an innovative magnetic lock designed for adding access control to chain link and ornamental metal swing gates. This lock is available in 2 versions, the MAG-3000 with 660 lbs. of holding force, and MAG-6000 with 1320 lbs. of holding force. The aluminum powder-coated housing with integrated design handles gives your access control gate that extra touch. Stop losing precious time with welding boxes by simply drilling 7 holes and utilizing the Quick-Fix which enables a fast and strong fixing. A two layer, protective coating guarantees that our electro-magnetic locks are ready for years of worry free use outside.

• High holding force! Up to 1320 lbs
• Guaranteed performance: holding force tested on every Maglock
• 500 hour salt spray resistant! SGS Certified.
• Tested according to ISO 9227
• Special two-layer protective coating developed for outdoor use
• Powder-coated aluminum casing
• Anti-residual magnetism kick-off system
• New anti-pry system: Raised edge on the magnet housing makes it impossible to put a crowbar between the magnet and the armature plate
• Integrated handles
• Fast and easy fixing by means of 7 holes with Quick-Fix
• Can be mounted on chain link fence gates using (3) Round Adapters (#6403)
• Same center-distance as the standard Locinox keeps
• Fail open
• MAG-3000: Minimal pulling force: 3000N (660 lbs)
• MAG-6000: Minimal pulling force: 6000N (1300 lbs)
• Voltage: 12V/24V DC
• Current MAG-3000: 500 mA / 12 V or 250 mA / 24 V
• Current MAG-6000: 460 mA /12 V or 230 mA / 24 V
• Tested to 500,000 cycles!
• 2-Year Manufacturer Warranty
