DAC Industries Superior Exit Bar Kit for Gates - Plate, D-6003 Bar with Lock Box

Item # D-6045-P

Actual product(s) may vary from pictures shown

DAC Industries Superior Exit Bar Kit Contents

D-6045 Panic Bar Kit Installed on Ornamental Metal Gate - Panic Bar Side

D-6045 Panic Bar Kit Installed on Ornamental Metal Gate - Lock Box Side

DAC Industries Superior Exit Bar Kit for Gates - Plate, D-6003 Bar with Lock Box (D-6045-P)

Details

The D-6045 Superior Surface Mount Exit Bar Kit includes the parts to mount a Detex V40 Value Series panic bar to a chain link or ornamental gate.

This kit allows for free exit/egress with keyed access from the outside of the gate.

D-6045 Surface Mount Exit Bar - Superior Kit Includes:

Detex D-6003 (36") or D-6004 (48") surface mount exit bar. (#D-6003 or D-6004)
Mounting plate, Adjusts for 32" to 54" gate frame. - 12" High (#D-6900) or 24" High (#D-6700)
Adjustable Receiver bracket for 3" O.D. (outside diameter) post (2-7/8" actual). (#D-6020)
Lock box for external access. (#D-6025)
Keyed cylinder with two keys. (#D-6014)
Pre-drilled holes for exit bar.
Stainless Steel tek-screws and fasteners.

Ordering Notes:

Height - Refers to Mounting Plate Height

Width - Refers to Panic Bar Width

Finish - Refers to Mounting Plate, Lock Box, and Adjustable Receiver Bracket

SKU	Size	Finish	Weight Each
D-6045-S36	12" High Plate for 36" Wide Gate	Silver	30.0 lbs.
D-6045-S36	24" High Plate for 36" Wide Gate	Silver	43.0 lbs.
D-6045-B36	12" High Plate for 36" Wide Gate	Black	30.0 lbs.
D-6045-B36	24" High Plate for 36" Wide Gate	Black	43.0 lbs.
D-6045-S48	12" High Plate for 48" Wide Gate	Silver	32.0 lbs.
D-6045-S48	24" High Plate for 48" Wide Gate	Silver	45.0 lbs.
D-6045-B48	12" High Plate for 48" Wide Gate	Black	32.0 lbs.
D-6045-B48	24" High Plate for 48" Wide Gate	Black	45.0 lbs.

Instructions

Detex Standard Panic Bar Kit Installation Guide (PDF)
