8 Gauge x 2" Chain Link Fence Fabric - Black, Brown, and Green

Details

8 gauge Extruded and Bonded chain link fence fabric is a great choice for high quality residential fence projects along with light commercial. With color coated chain link fence customers to choose a fence that will accentuate siding, roofing, and trim colors on houses and business. Some choose the colored option because it will blend into the natural surroundings.

We offer a full line of colored framework, fittings, and gates to match the fabric. Customers may also choose to pair the colored fabric with galvanized framework, which is also common practice.

An added benifit of this material is that the steel core wire is galvanized, then covered in a 'glue', and finally the material has PVC extruded over the wire which adds an additional protective layer to the steel wire.

Volume discounts provided on full pallet quantities (9 rolls).

KxK Selvage = Knuckle x Knuckle (Chain link top and bottoms are bent over).

KxT Selvage = Knuckle x Twist (Chain link is twisted at one end to form two barbs, while the other is bent over).

Chain Link Fabric Selvage Diagram

Specifications

8 gauge Vinyl Extruded and Bonded chain link fence fabric has an 11 gauge steel core which is coated with a 'glue' and then coated in vinyl. This material finishes out at an 8 guage finish.

This fabric meets Federal Specifications: RR-F-191/1D, Type IV; ASTM F-668, Class 2A

A special order option would be fused and bonded. This is typically used in heavy commercial or industrial projects.

What is the difference between 'Extruded' and 'Extruded and Bonded'? In layman's terms, Extruded Vinyl, when cut with a knife, can be peeled off like a banana. However, it does not peel easily. Extruded and Bonded Vinyl is also adhered to the wire and would have to be cut off completely, much like peeling a potato. Extruded costs less than Extruded and Bonded.

About mesh size: The galvanized fabric mesh for 11-1/2 gauge measures 2-1/4". The 11, 9, and 6 gauge galvanized mesh measures 2". Mesh size is the measured distance between two parallel sides (see illustration).

Note about gauges: The smaller the number, the heavier the fabric; henceforth 9ga. is heavier than 11ga.. We recommend 11ga. for residential jobs and 9ga. for commercial jobs. Heavier gauges are not only stronger, but have a better finish; The heavier the gauge the longer it may be 'hot-dip galvanized' to prevent rust and corrosion.

Fence Height	Weight per 50' Roll
3'	75 lbs.
3-1/2'	88 lbs.
4'	100 lbs.
5'	125 lbs.
6'	150 lbs.
7'	175 lbs.
8'	200 lbs.
10'	150 lbs.
12'	300 lbs.

Weights shown are approximate.

Instructions

Rolls are supplied with an additional link for weaving onto another roll of material if over 50' is needed. On the flip side, a full roll can easily be trimmed down by un-knuckling (un-folding) the links on the ends and spinning the link out to one side of the roll.

Chain Link Fence Installation Manual (PDF)
