SHUT IT! The BadAss VersaWeld Hinge

Item # CI3075

Sold Individually

Actual product(s) may vary from pictures shown

SHUT IT! The VersaWeld BadAss Hinge (CI3075)

Details

Shut It Sell Sheet | D&D Technologies Catalog

The BadAss VersaWeld Hinge (CI3075)

The BadAss VersaWeld – a simple hinge that welds on nearly any gate right out of the box. CNC machined to the tightest tolerances in the industry. Due to SHUT IT’s unique bushing design The VersaWeld, like all other SHUT IT gate hinges, produces near frictionless movement with maintenance free usage.

The BadAss VersaWeld Hinge (CI3075) Features:

One simple hinge that welds on nearly any gate right out of the box
Fits either flat or round posts or gates no adaptors needed
High-temp bearings, safe to powder-coat with hinges installed on gate
Smoother than traditional block or barrel hinges
2 sealed ball bearings
No greasing, no maintenance. EVER!
Precision bushing distributes gate load for optimal performance and hinge longevity
Load rating per gate: 2,000 lb (900kg)
Maximum gate weight: 1,100 lb (500kg)
Approx Gate Size: 6ft W x 8ft H (1.5m x 2m)
Gate Frame/Post Shape: Square-to-Square, Square-to-Round, Round-to-Round, Round-to-Square
Min Post Size: 1-1/2"+ (38mm)
Ideal Gate Gap: Fixed at 2-3/4" (70mm)
Fixing Method: Weld-On
Color/Finish: Zinc

Specifications

SKU	Finish	Fixing	Gate Gap	Bracket	Body	Height	Weight
CI3075	Zinc	Weld-On	Flat posts: Fixed 2.75" (70mm). Round posts: no gap.	Steel	Steel	3-47/64" (95mm)	2.2 lb (1kg)

Product Code	CI3075
Gate Application	Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate
Gate Type	Non Self-Closing
Gate Material	Steel/Ornamental Iron
Approx Gate Size	6ft W x 8ft H (1.5m x 2m)
Gate Frame/Post Shape	Square-to-Square, Square-to-Round, Round-to-Round, Round-to-Square
Min Post Size	1-1/2"+ (38mm)
Ideal Gate Gap	Fixed at 2-3/4" (70mm)
Fixing Method	Weld-On
Color/Finish	Zinc
