Our Color Coated Residential Chain Link Double Swing Gates feature a fully welded color coated gate frame and matching 9 gauge fabric of your choice. The corners are notched and welded for added strength and rigidity. We then clean and paint the welded joints with a color-match welders paint which protects from corrosion. The chain link fabric is attached to the gate uprights with tension bars and tension bands while aluminum tie wires attach the fabric at all horizontal rail connections. Our gates ship assembled, and do not include hardware.
Residential chain link fence double gates are available in Black, Brown, or Green, in heights of 3', 3-1/2', 4', 5', and 6', for opening sizes of 10' and 12' wide.
If you are purchasing a gate with colored chain link we can not guarantee the color will match an existing fence. If you are purchasing a job-lot from us then the color will match the chain link fabric on your order. Black is black, but brown, green, and white may vary slightly from one lot to another or between manufacturers. Unfortunately, we can not match your existing colors even with a sample.
Ordering Notes:
Our gates are built to fit the opening size shown, the space in-between the hinge posts or the hinge and latch post. Gates are also built approximately 2" shorter than the heights shown to allow space under the gate for it to swing. We can build to 'finish size' by request. Custom built sizes and configurations by special request. Please contact a sales representative for all custom requests. Custom fee's start at $15.
Actual designs may vary from what is pictured depending on size of gate. Gates do not include a decorative scroll though we do have them available separately. We also offer matching single gates along with galvanized framed options.
Actual Double gate widths are approx. 6" less than the width shown. This allows space for our standard strap hinges and drop rod assembly (not included).
Example: a 10' (120") wide double gate's leaf actually measures approximately 57" wide each.
If you are using your hinges, set the posts after the gate arrives by pre-mounting the hinges and latch to guarantee a proper fit. This is always a good idea anyway. TIP: Set the gate hinge post first, install the gate complete with latch and set the latch post last. This GUARANTEES a good fit. We can custom build to fit your opening between posts, or other fixed structures, i.e. walls, and/or columns.
If you are replacing an existing gate, you must measure the gate opening size and make sure gate posts are plumb. Measure across the opening at a height where you intend to mount the latch. Provide us with the 'inside-to-inside' measurement. Provide us with the gate opening size and we will make the gate fit using our hinges and latch. It would also be wise to measure the actual height of the gate, in the case that our standard 2 inch space under the gate does not meet your needs. Please provide a drawing with all pertinent measurements at the time of your order.
Here are some great pictures from our customer Shaun up in Alberta, Canada, of a black chain link fence double date, featuring winged privacy slats, and installed on his cedar privacy fence using our Snug Cottage Mounting Plate with 8" Adjustable Threaded Pins, in a black finish. This project turned out great and is a beautiful blend of wood and and black chain link fence. Thank you very much Shaun!
