When you need increased privacy, PDS Winged Slat® is the answer. With the proven quality and durability of our standard slats plus unique "wings" for extra screening and security, these slats are self-locking - no channels are needed!
Winged slats are sold in bags which provide approximately 10 linear feet of coverage (each bag contains 82 individual slats). All slats are also approximately 2" shorter that the actual height of fence.
To install, simply insert vertical slats with angle cut end downward. Winged portion interlocks with chain link knuckles. No special tools are needed, but a pair of Fence Pliers come in handy to straighten any wire that is deformed or bent. Note: These are friction-fitting Fence Slats, additional time should be allowed for installation.
Note: The Top Lock Chain Link Fence Slat is designed to work with a fence that has a mesh size of 2" or larger. This means that they will typically work well with an 11 gauge, 9 gauge, 8 gauge, or 6 gauge chain link fence mesh. It is best to double check your mesh size before ordering.
DESIGN: Our innovative Winged Slat has a rigid, flat tubular body, with "legs" inside for extra support and durability. Flexible and resilient wing portions are positioned on each side of the slat body. Serrations are added to the wings for easier installation and locking power.
STANDARD HEIGHTS: 4', 5', 6', 7', and 8'. Important: For Fence heights higher than 8 feet, we strongly advise NOT to double-stack Winged Slats. If you double-stack, you will be at risk of the Winged Slats not all giving the same visual appearance or giving the same privacy effect on the top and bottom portions of the Fence.
SLAT LENGTH: 2" shorter than overall height of fence.
COLOR CHOICES: Black, Brown, Green, White, Gray, Royal Blue, Light Blue, Beige, and Redwood.
WIND LOAD AND PRIVACY FACTOR: Approximately 90%. (Based on wire/mesh used - stretch tension). Note: Customer is responsible for ensuring sufficient structural support for additional wind load.
MATERIALS: The Winged Slat product is extruded from High Density Polyethylene (HDPE), color pigments and ultra violet (UV) inhibitors, specifically designed to retard the harmful effects of the sun and lengthen the life of the product. Winged Slats include Ethyl Vinyl Acetate (EVA), a softer plastic to keep the wings flexible and resilient.
DURABILITY: Pexco PDS® HDPE Fence Products are resistant to: severe weather conditions, salt water, sand, road dirt, most acids, alcohol, alkaline, ammonia, petroleum distillates and common environmental pollutants.
MAINTENANCE: Pressure cleaning of surface contaminants is quickly accomplished with plain water.
25 YEAR LIMITED WARRANTY: Top Lock carries a 25-year, pro-rata warranty against breakage under normal conditions.
Here are some great pictures from our customer Shaun up in Alberta, Canada, of a black chain link fence double date, featuring winged privacy slats, and installed on his cedar privacy fence using our Snug Cottage Mounting Plate with 8" Adjustable Threaded Pins (8256-34P), in a black finish. This project turned out great and is a beautiful blend of wood and and black chain link fence. Thank you very much Shaun!
Average Customer Rating:
(18 Reviews)
Write a Review (requires login)
Excellent service when ordering, delivering and easy to install the wing slats in the chain link fence for privacy. Great product.
I ordered some slats for my fence and received them in a couple days. They installed easy and look great.
The slats were easy to install. Very good product.
Amazing customer service
Very easy to use product. It worked very well. I only wish you could buy individual pieces for repair to damaged slats.
