Our Industrial Chain Link Single Swing Gates feature a robust welded 2" HF40 galvanized gate frame streched with 9 ga. galvanized fabric. The corners are notched and welded for a strong and aesthetic finish. We then clean and paint the welded joints with a zinc-rich welders paint. The chain link fabric is attached to the gate uprights with tension bars and tension bands, and aluminum tie wires attach the fabric at all horizontal rail connections. Our gates ship assembled, and do not include hardware.
We also offer double gates, gates with barbed wire, and full colored gates. Custom built sizes and configurations by special request. Please contact a sales representative for all custom requests.
Note on Sizing and Design:
Our gates are built to fit the opening size, the space in-between the hinge posts or the hinge and latch post. Gates are also built approximately 2" shorter than the heights shown to allow space under the gate. We can build to 'finish size' by request. Actual designs may vary from what is pictured depending on size of gate.
Gates 5' high and higher have a horizontal brace. Gates over 7' wide have a vertical brace. If both dimensions are exceeded, gates will have both vertical and horizontal bracing.
Actual Single gate widths are approx. 4" less than the width shown. This allows space for our standard hinges and fork latch (not included).
Example: a 4' (48") wide gate actually measures approximately 44" wide.
If you are using your hinges, set the posts after the gate arrives by pre-mounting the hinges and latch to guarantee a proper fit. This is always a good idea anyway. TIP: Set the gate hinge post first, install the gate complete with latch and set the latch post last. This GUARANTEES a good fit. We can custom build to fit your opening between posts, or other fixed structures, i.e. walls, and/or columns.
If you are replacing an existing gate, you must measure the gate opening size and make sure gate posts are plumb. Measure across the opening at a height where you intend to mount the latch. Provide us with the 'inside-to-inside' measurement. Provide us with the gate opening size and we will make the gate fit using our hinges and latch. It would also be wise to measure the actual height of the gate, in the case that our standard 2 inch space under the gate does not meet your needs. Please provide a drawing with all pertinent measurements at the time of your order.
